    SGM3838YG_TR Triple-Output Converters 700mA AMOLED Display Power Supply

    Ask Lasest Price
    Brand Name : SGMICRO
    Model Number : SGM3838YG_TR
    Price : Email us for details
    Payment Terms : Paypal,TT,Western Union
    Supply Ability : 5000
    Delivery Time : 1day
    • Product Details
    • Company Profile

    SGM3838YG_TR Triple-Output Converters 700mA AMOLED Display Power Supply

    SGM3838YG_TR Triple-Output 700mA AMOLED Display Power Supply
    SGMICRO
    Product Category:Triple-Output converters
    WLCSP-2.5×2.5-36B
    SMD/SMT
    Brand:SGMICRO
    Product Type:converters
    Subcategory:Triple-Output converters
    Unit Weight:0.084185 oz

    FEATURES

    • Synchronous Inverting Buck-Boost Converter (ELVSS)-6.0V to -0.8V Output Voltage with 100mV Steps-3.0V Default

    Output Voltage1% Accuracy at -3V700mA Output Current Capability
    • Synchronous Boost Converter (AVDD)5.5V to 7.9V Output Voltage with 100mV Steps7.3V Default Output Voltage0.9%

    Accuracy at 7.3V150mA Output Current Capability
    • VIN and VOUT Bi-Directional Isolation
    • Short Circuit Protection (SCP)
    • Overload Protection
    • Thermal Shutdown
    • VELVSS Start-Up Delay: 5.6ms
    • Short Circuit and OLP Detection Time: 0.71ms

    • Available in a Green WLCSP-2.5×2.5-36B Package


    Description

    The SGM3838 is designed for powering AMOLED displays which requires VELVDD, VELVSS and VAVDD. The device

    integrates two boost converters, VO1 for VELVDD and VO3 for VAVDD, and a dual-phase inverting Buck-Boost converter

    VO2 for VELVSS. Output voltages of all the three converters can be programmed in digital steps through the digital

    interface control pin (SWIRE).

    The SGM3838 is available in a Green WLCSP-2.5×2.5-36B package.


    Application

    • Smartphones & Tablets
    • Active Matrix OLED Displays
